RS232 To TTL Serial Port Converter Module

SKU: VM00206

Price:
Sale price Rs. 42.37 (excl.18% GST)
Rs. 50.00

Description

This RS232 to TTL Serial Interface Module is a board with the MAX3232 transceiver integrated circuit (IC). It facilitates serial communication between TTL and RS232 ports by providing the necessary electrical signal conversion. These boards usually have a DB9 connector soldered at one end, and four header pins with jumper cables at the other end. The jumper cables enable the user to connect the wires to a breadboard or a microcontroller project board, whilst the DB9 connects directly to a COM port of a computer. The MAX3232CSE+IC, which comes in a 16 pin narrow SO package. It requires between 3.0 V to 5.5 V to operate and has two receivers and two transmitters. It has a maximum guaranteed data rate of 120 kbps, and the circuitry requires four 0.1µF charge-pump support capacitors. It is also compatible with the famous MAX3232 IC pins. These boards connect to systems with a UART hence, they work with ATMEL and PIC & microcontrollers.

Technical Specification:

  • IC Chip: MAX3232
  • Operating Voltage: 3.3-5.5V
  • Operating current: 6mA
  • Power supply: external
  • Interface: TXD, RXD, GND, VCC
  • Size: 45mm*32mm*15mm (L*W*H)

Features:

  • Easy to use and low cost
  • No need of any soldering just plug and play
  • Compatible with most of the microcontrollers which operate on either 3.3V and 5V
  • Robust and can be used in Industrial applications too
  • Pre-assembled compact size board
  • Suitable for use with most microcontrollers
  • Operates up to 250 kbit/s

Applications:

  • Radio modification
  • Phone flash
  • GPS, vehicle detection
  • DVD flash
  • Hard disk repair set-top box upgrade
